APPLICATION SCOPE:
Could used in different household water supply surrounding, such as villa, duplex and penthouse etc. Not only could increase the water pressure delivery by the mains. Increase the water pressure from roof tanks but also be used to boost hot water pressure or circulate.
TECHNICAL DATA:
| Model | CUBE 3.0 |
|---|---|
| Fullload Current (A) | 4.5A |
| Max Power | 750W |
| Hmax | 45m |
| Qmax | 5.5m3/h |
| Rated Head | 30m |
| Rated Flow | 3m3/h |
| Inlet/Outlet | 25mm |
| Temperature | 0-95C |
| Max RPM | 4800r/min |
FEATURES:
50% energy saving than normal motor, 4800 max
A total smart pump is able to adjust the performance in variable speed according to water demand, provide constant pressure
The pump with a permanent magnet motor to reduce power consumption while the variable speed control matches the power consumption with the required water demand
